Compact. Modular. Built for Smart Urban Lighting.
Multi-section pole segments with slip joint or flange connection simplify transportation and on-site assembly.
Hot-dip galvanized with ≥85μm zinc coating, plus optional powder coating in custom RAL colors.
Available in 5 standard sizes: 2.5m, 3m, 4m, 5m, and 6m – ideal for diverse applications like footpaths, courtyards, and public areas.
Supports various lighting arms or top-mount LED fixtures, available with custom mounting holes and spacing.
Clean, modern aesthetic with tapered design for strength and stability while maintaining a slim profile.
Designed for batch production, container optimization, and quick on-site setup with minimal labor.

| Model | GB-ROTS | F | G | R | R | R |
| Product Picture | ![]() | ![]() | ![]() | ![]() | ![]() | ![]() |
| H(M) | 2m | 2m | 2m | 2m | 2m | 2m |
| Section 1 | ø76*1000*1.5mm | ø76*1000*1.5mm | ø76*1000*1.5mm | ø76*1000*1.5mm | ø76*1000*1.5mm | ø76*1000*1.5mm |
| Section 2 | ø76*1000*1.2mm | ø76*1000*1.2mm | ø76*1000*1.2mm | ø76*1000*1.2mm | ø76*1000*1.2mm | ø76*1000*1.2mm |
| Section 3 | - | - | - | - | - | - |
| Section 4 | - | - | - | - | - | - |
| Section 5 | - | - | - | - | - | - |
| E*F | 210*6mm | 210*6mm | 210*6mm | 210*6mm | 210*6mm | 210*6mm |
| Package Size | 1010*170*185mm | 1010*170*185mm | 1010*170*185mm | 1010*170*185mm | 1010*170*185mm | 1010*170*185mm |
| Weight | 5.5kg | 5.5kg | 5.5kg | 5.5kg | 5.5kg | 5.5kg |
| Anchor Bolts | 160*160*14*300mm | 160*160*14*300mm | 160*160*14*300mm | 160*160*14*300mm | 160*160*14*300mm | 160*160*14*300mm |




| Model | Package Size | Weight |
| 2m | 1010*170*185mm | 5.5kg |
| 2.5m | 1020*230*240mm | 8.0kg |
| 3m | 1050*260*255mm | 10.2kg |
| 4m | 1050*260*255mm | 12kg |
| 5m | 1050*260*255mm | 14kg |
| 6m | 1550*260*255mm | 17.5kg |
